Performance

Video input channels

8 channels

Maximum resolution

3840 x 2160 pixels

Supported resolutions

3840 ×2160, 1920 × 1080, 1680× 1050, 1440 × 900, 1280 × 1024, 1280 × 720

Video motion detection

Yes

Video loss detection

Yes

Multi-screen

Yes

Input bandwidth

80 Mbit/s

Output bandwidth

60 Mbit/s

Wireless LAN features

Wi-Fi

Yes

Wi-Fi standards

802.11b, 802.11g, Wi-Fi 4 (802.11n)

Wi-Fi data rate (max)

300 Mbit/s

Hard drive

HDD capacity

0 GB

Maximum storage capacity

16 TB

HDD interface

SATA

Ports & interfaces

Ethernet LAN (RJ-45) ports

2

Ethernet LAN data rates

10,100 Mbit/s

Ethernet WAN

Yes

HDMI ports quantity

1

VGA (D-Sub) output ports

1

USB 2.0 ports quantity

2

DC-in jack

Yes

Features

LED indicators

Yes

Reset button

Yes

Product colour

White

Power

Power consumption (typical)

5.7 W

Operational conditions

Operating temperature (T-T)

-10 - 55 °C

Operating relative humidity (H-H)

10 - 90%

Storage temperature (T-T)

-40 - 70 °C

Storage relative humidity (H-H)

10 - 90%

Weight & dimensions

Width

200.3 mm

Depth

200.3 mm

Height

43 mm

Weight

500 g

Package weight

1 kg
