Introduction

75" 4K UHD Professional Digital Signage 24/7 display featuring Android OS, FailOver and Intel® SDM slot

Choose non-stop high performance and reliability with the ideal all-in-one signage solution for mission critical environments. The LH7575UHS from iiyama can be operated in landscape or portrait orientation in continual around the clock environments, 24/7 without any interruption. Its versatility can be adapted to your industry’s display needs. On-board Android 11 OS means you can easily customize the display to your needs and install applications directly to it.

The on-board iiSignage² (Content Management System) gives you total control of your messaging and advertising remotely and safely. The SDM Slot provides embedded PC option for total flexibility, security and control, while the FailOver feature ensures your content is always actively displayed through your choice of inputs. The built-in (and removable) WiFi module means this series is ready for remote content delivery using your network.

With the EShare app you bring effortless ideation and efficient collaboration in your enterprise or school. You can start sharing wirelessly easier than ever before.

ANDROID OS
Thanks to Android OS, you can easily customize the display to your needs by installing applications directly to it.

IISIGNAGE²
iiSignage² is our digital signage content management platform to easily show and control your content and to manage your displays in a secure way. The Content Management System (CMS) gives you total control of your messaging and advertising remotely and safely.

SIGNAL FAILOVER
FailOver is a feature which automatically detects input sources. When there is no signal on the default input it will automatically switch to the next available input. FailOver allows customers to prioritize a number of inputs (incl. Browser, Media Player and Custom) and ensures your content is always actively displayed, assuring active content at all times.

SMART DISPLAY MODULE
A Smart Display Module (Small/Large) is a plug-in module which can easily be inserted into the most stylish and ultra-slim displays. This small sized module delivers great performance with minimum implementation and management. Available as optional.

4K
UHD resolution (3840x2160), better known as 4K, offers a gigantic viewable area with 4 times more information and work space than a Full HD screen. Due to the high DPI (dots per inch), it displays an incredibly sharp and crisp image.

Display

Panel type

IPS

Display diagonal

190.5 cm (75")

Display technology

LCD

Display resolution

3840 x 2160 pixels

Display brightness

500 cd/m²

HD type

4K Ultra HD

Touchscreen

No

Native aspect ratio

16:9

Response time

8 ms

Contrast ratio (typical)

1200:1

Viewing angle, horizontal

178°

Viewing angle, vertical

178°

Display number of colours

1.07 billion colours

Pixel pitch

0.429 x 0.429 mm

Active display area (W x H)

1650 x 928 mm

Display diagonal (metric)

189.3 cm

Maximum frame rate

60 fps

Horizontal scan range

28 - 160 kHz

Haze rate

25%

RGB colour space

sRGB

Ports & interfaces

HDMI ports quantity

3

HDMI version

2.0

DisplayPorts quantity

1

DisplayPort version

1.2

USB port

Yes

USB ports quantity

2

USB version

2.0

Ethernet LAN

Yes

Ethernet LAN (RJ-45) ports

1

Wi-Fi

Yes

Wi-Fi standards

Wi-Fi 5 (802.11ac)

PC Audio in

Yes

RS-232C

Yes

Remote (IR) input

1

Remote (IR) output

1

Card reader integrated

Yes

Compatible memory cards

MicroSD (TransFlash)

Audio

Built-in speaker(s)

Yes

Number of built-in speakers

2

RMS rated power

20 W

Design

Product design

Digital signage flat panel

Placement supported

Indoor

Orientation

Horizontal/Vertical

Product colour

Black

VESA mounting

Yes

Panel mounting interface

600 x 400 mm

Bezel width (bottom)

1.49 cm

Bezel width (side)

1.49 cm

Bezel width (top)

1.49 cm

Performance

Purpose

Universal

On Screen Display (OSD)

Yes

Number of OSD languages

15

On Screen Display (OSD) languages

Simplified Chinese, Czech, Danish, German, Dutch, English, Spanish, Finnish, French, Italian, Japanese, Polish, Russian, Swedish

Operating hours (hours/days)

24/7

HDCP

Yes

HDCP version

2.2

Mean time between failures (MTBF)

44000 h

Power

Power consumption (typical)

189 W

Power consumption (standby)

0.5 W

Power consumption (off)

0.5 W

Energy efficiency class (SDR)

G

Energy consumption (SDR) per 1000 hours

189 kWh

AC input voltage

100 - 240 V

AC input frequency

50 - 60 Hz

Energy efficiency scale

A to G

Computer system

Built-in processor

Yes

Processor manufacturer

ARM

Processor family

ARM Cortex

Processor architecture

ARM Cortex-A53+Cortex-A73

Processor cores

4

Internal memory

4 GB

On-board graphics card model

ARM Mali-G52

Internal storage capacity

32 GB

Operating system installed

Android 11

Weight & dimensions

Display width

1679.5 mm

Display depth

55 mm

Display height

958.5 mm

Display weight

29.5 kg

Packaging data

Package width

1883 mm

Package depth

186 mm

Package height

1140 mm

Package weight

41 kg

Packaging content

Remote control included

Yes

Batteries included

Yes

Cables included

AC, HDMI, RS-232

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Storage temperature (T-T)

-20 - 60 °C

Certificates

Certification

CB, CE, TÜV-Bauart, EAC, ErP, WEEE, REACH

Logistics data

Harmonized System (HS) code

85285210

Technical details

Compliance certificates

RoHS

Other features

Quick start guide

Yes

Housing material

Metal
