Introduction
Indoor/outdoor 2K PoE camera with pan-tilt-zoom functionality that offers full 360° surveillance.
Performance
Type
IP security camera
Placement supported
Indoor & outdoor
Connectivity technology
Wired
PTZ control
Yes
Infrared (IR) cut-off filter
Yes
Remote viewing
Yes
Processor model
ARM Cortex-A53
Built-in processor
Yes
Design
Form factor
Dome
Mounting type
Ceiling/wall
Product colour
White
LED indicators
Yes
Housing material
Aluminium, Polycarbonate (PC), Stainless steel
Protection features
Vandal proof
International Protection (IP) code
IPX4
IK code
IK08
Weatherproof
Yes
Camera
Field of view (FOV) angle
360°
Image sensor
Sensor type
CMOS
Lens system
Number of lenses
1
Night vision
Night vision
Yes
Night vision distance
9 m
LED type
IR
Video
Maximum resolution
1920 x 1920 pixels
Total megapixels
5 MP
Video compression formats
H.264, M-JPEG
Frame rate
30 fps
Video streaming
Yes
Image quality adjustment
Brightness, Colour depth, DNR, Sharpness
Text caption overlay
Yes
Audio
Built-in speaker(s)
Yes
Audio system
2-way
Built-in microphone
Yes
Network
Ethernet LAN
Yes
Ethernet interface type
Gigabit Ethernet
Networking standards
IEEE 802.3af
Wi-Fi
No
Bluetooth
No
Storage
Flash memory
8000 MB
RAM capacity
2000 MB
Ports & interfaces
Ethernet LAN (RJ-45) ports
1
Management features
Web-based management
Yes
Reset button
Yes
Smartphone/tablet remote support
Yes
Power
Power source type
PoE
Power consumption (max)
8.64 W
Operational conditions
Operating temperature (T-T)
-20 - 40 °C
Operating relative humidity (H-H)
10 - 90%
System requirements
Mobile operating systems supported
Android, iOS
Weight & dimensions
Height
49 mm
Diameter
14.7 cm
Weight
655 g
Sustainability
Compliance certificates
CE, Federal Communications Commission (FCC), Industry Canada (IC)
Packaging content
Number of cameras
1
Manual
Yes
Technical details
Voltage
37 - 57 V
