Performance
Video input channels
16 channels
Alarm input channels
16
Alarm output channels
4
Number of simultaneously playbacked channels
16 channels
Video recording modes
720p, 1080p
Maximum resolution
3840 x 2160 pixels
Supported resolutions
3840x2160/30Hz, 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz
Video motion detection
Yes
Video loss detection
Yes
Video formats supported
H.264, H.264+, H.265, H.265+
Backup function
Yes
Playback modes
Digital zoom, Fast play, Forward, Full screen, Pause, Play, Stop
Input bandwidth
320 Mbit/s
Output bandwidth
320 Mbit/s
Recording modes
Manual, Schedule
Audio system
2-way
Hard drive
HDD capacity
0 GB
Number of HDDs supported
4
Maximum storage capacity
16 TB
HDD interface
SATA
Ports & interfaces
Ethernet LAN (RJ-45) ports
2
Ethernet LAN data rates
10,100,1000 Mbit/s
HDMI ports quantity
2
VGA (D-Sub) output ports
1
USB 2.0 ports quantity
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
1
eSATA ports quantity
1
Line-in
Yes
Audio output
1
RS-232 ports
1
Supported network protocols
UPnP (Plug and Play), NTP (Network Timing), SMTP, DNS, TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, RTSP, SSL/TLS, RTP, IPv4, ARP
Features
Rack mounting
Yes
Reset button
Yes
Buzzer off
Yes
Product colour
Black
Power
Power consumption (max)
45 W
AC input voltage
100 - 240 V
AC input frequency
50/60 Hz
Output current
1.5 A
System requirements
Mobile operating systems supported
Android, iOS
Browser supported
Chrome (57+), Firefox (52+), Edge (91+)
Operational conditions
Operating temperature (T-T)
-10 - 55 °C
Operating relative humidity (H-H)
10 - 90%
Weight & dimensions
Width
440 mm
Depth
330 mm
Height
44 mm
Weight
4 kg
Package width
440 mm
Package depth
528 mm
Package height
100 mm
Package weight
5 kg
Packaging content
Cables included
AC, Power
Quick installation guide
Yes
