Introduction

To Be Future-Ready

The AI era is upon us. Are you ready for the transformation in work and everyday life? Let's work together with the Modern AM273Q AI Series to embrace the next-level AI experience with faster, power-saving, AI-enabled processors.

MSI AI Engine

MSI AI Engine automatically detects user scenarios and adjusts performance, sound effects, and display mode accordingly, eliminating the need for manual adjustments.

Windows Studio Effects

Using AI to enhance videos with features like background effects, eye contact correction, automatic framing, and voice focus for professional and engaging video conferencing.

Eye-Q Check

With Eye-Q check, you can self-access your eye health while working long hours, preventing eye problems from escalating.

WQHD (2560 x 1440)

WQHD (2560 x 1440) resolution expands your workspace, providing sharper readability, vivid 3D effects, and enhanced aesthetics for a better user experience.

Built for Sustainability

The MSI All-in-One PCs blend business-centric design with environmental responsibility - an embodiment of MSI's dedication to sustainability. Our commitment extends to incorporating sustainable materials in both our product design and packaging, protecting the earth through our actions. By utilizing sustainable materials such as PCR plastics, recycled pulp from FSC™-certified forests, more active management of substances used in manufacturing processes, and the continued use of renewable energy in production processes, we ensure the products' durability and a commitment to a greener world.

The MSI All-in-One PCs embody sustainable value and heightened productivity.

Display

Display diagonal

68.6 cm (27")

Display resolution

2560 x 1440 pixels

Touchscreen

No

HD type

Wide Quad HD

Display brightness

300 cd/m²

Panel type

IPS

Pixel pitch

0.2331 x 0.2331 mm

Anti-glare screen

Yes

Tilt adjustment

Yes

Tilt angle range

-5 - 20°

Processor

Processor manufacturer

Intel

Processor family

Intel Core Ultra 7

Processor generation

Intel® Core™ Ultra (Series 1)

Processor model

155H

Processor cores

16

Processor threads

22

Processor boost frequency

4.8 GHz

Performance cores

6

Efficient cores

8

Low Power Efficient-cores

2

Performance-core Max Turbo Frequency

4.8 GHz

Efficient-core Max Turbo Frequency

3.8 GHz

Low Power Efficient-core Max Turbo Frequency

2.5 GHz

Performance-core base frequency

1.4 GHz

Efficient-core base frequency

0.9 GHz

Low Power Efficient-core Base Frequency

700 MHz

Processor cache

24 MB

Processor cache type

Smart Cache

Processor base power

28 W

Maximum turbo power

115 W

Neural processor unit (NPU)

Neural processor unit (NPU)

Intel AI Boost

Maximum frequency NPU

1.4 GHz

Sparsity support

Yes

Windows Studio effects support

Yes

AI software frameworks supported by NPU

DirectML, ONNX RT, OpenVINO, Windows ML

Memory

Internal memory

32 GB

Internal memory type

DDR5-SDRAM

Maximum internal memory

64 GB

Memory slots

2

Memory slots type

SO-DIMM

Memory clock speed

5600 MHz

Memory layout (slots x size)

2 x 16 GB

Memory form factor

DIMM/SO-DIMM

Storage

Total storage capacity

1 TB

Storage media

SSD

Total SSDs capacity

1 TB

Number of SSDs installed

1

SSD capacity

1 TB

SSD interface

PCI Express 4.0

NVMe

Yes

SSD form factor

M.2

M.2 SSD size

2280 (22 x 80 mm)

Optical drive type

No

Card reader integrated

Yes

Graphics

Discrete graphics card

No

Discrete graphics card model

Not available

On-board graphics card

Yes

On-board GPU manufacturer

Intel

On-board graphics card family

Intel Arc Graphics

On-board graphics card model

Intel Arc Graphics

Audio

Built-in speaker(s)

Yes

Number of speakers

2

RMS rated power

6 W

Audio chip

Realtek ALC256

Camera

Built-in camera

Yes

Total megapixels

2 MP

Camera HD type

Full HD

Network

Wi-Fi

Yes

Top Wi-Fi standard

Wi-Fi 6E (802.11ax)

Wi-Fi standards

Wi-Fi 6E (802.11ax)

WLAN controller manufacturer

Intel

WLAN controller model

Intel Wi-Fi 6E AX211

Ethernet LAN

Yes

Bluetooth

Yes

Bluetooth version

5.3

Ports & interfaces

Ethernet LAN (RJ-45) ports

1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

5

HDMI ports quantity

2

HDMI version

2.0

Combo headphone/mic port

Yes

Design

Product colour

Black

Cable lock slot

Yes

Cable lock slot type

Kensington

VESA mounting

Yes

Panel mounting interface

100 x 100 mm

Performance

Product type

All-in-One PC

Motherboard chipset

Intel SoC

Trusted Platform Module (TPM)

Yes

Software

Operating system installed

Windows 11 Pro

Processor special features

Intel Virtualization Technology for Directed I/O (VT-d)

Yes

Power

AC adapter power

120 W

Weight & dimensions

Width (with stand)

638.1 mm

Depth (with stand)

180.7 mm

Height (with stand)

433.1 mm

Weight (with stand)

5 kg

Package width

700 mm

Package depth

217 mm

Package height

473 mm

Package weight

9.6 kg

Operational conditions

Operating temperature (T-T)

0 - 35 °C

Storage temperature (T-T)

-20 - 60 °C

Operating relative humidity (H-H)

0 - 85%

Storage relative humidity (H-H)

0 - 90%

Certificates

Certification

CB/CE

Other features

Warranty period

3 year(s)
