Introduction

The HPE Networking Instant On Secure Gateway is a powerful, cloud-managed security solution designed for small and growing businesses. It delivers enterprise-grade security—firewall, IDS/IPS, VPN, PoE, and WAN resiliency—without hidden fees or licenses. Managed through a single platform, it offers domain blocking, deep packet inspection, and 24x7 network monitoring to protect against cyberthreats. Designed with ease of use in mind, it enables minimum-touch deployment and automated configuration, making network setup and management accessible even for non-technical users. Ideal for securing customer data, transactions, and multi-site connectivity, this gateway provides easy, reliable control tailored to SMB needs, combining simplicity with top-tier protection.

Active Threat Monitoring with Intrusion Detection and Prevention (IDS/IPS)
- IDS and IPS monitor network traffic for suspicious activities. IDS detects and alerts administrators about potential security breaches, while IPS actively blocks or prevents threats in real-time.
- Together, IDS and IPS enhance network security by identifying and responding to potential intrusions.

Keep the Network Safe with a Stateful Firewall
- This monitors and controls network traffic based on policies, creating a barrier between trusted internal networks and untrusted external networks to prevent unauthorized access and cyber threats.
- Default settings block external traffic from accessing the LAN. policies can allow or block traffic, enable port-forwarding, and client access.

Keep the Business Online with WAN Resiliency
- This feature enables continuous connectivity during network disruptions using multiple ISP connections.
- The secure gateway detects issues (link degradation or failure) and reroutes traffic to the best available ISP uplink, reducing downtime and service interruptions.

Design

Product colour

White

Mounting type

Desktop/Wall mounting

Performance

Built-in processor

Yes

Processor frequency

2000 MHz

Internal memory

2048 MB

Flash memory

4096 MB

Network

Ethernet LAN data rates

10,100,1000 Mbit/s

Firewall throughput

980 Mbit/s

Ports & interfaces

Ethernet LAN (RJ-45) ports

4

WAN connection

Ethernet (RJ-45)

Power

Power consumption (max)

12 W

Power consumption (idle)

2.3 W

Input voltage

100 - 240 V

Input frequency

50/60 Hz

Weight & dimensions

Width

164.1 mm

Depth

190 mm

Height

43.9 mm

Weight

1.03 kg

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

15 - 95%
