Introduction

The Elo 15-inch X-Series is an innovative, all-in-one, standard-aspect touchscreen computer that offers a sleek form factor with flexibility, power and endless configuration possibilities. With a compact design, the X-Series is ideal for applications in any retail, self-service or hospitality environment that requires a small footprint POS terminal or kiosk. The highly versatile platform provides maximum configurability and offers you unprecedented freedom of choice in the design of your AiO system.

Configurability.
A wide range of size, processor, interface, storage, expansion, operating system and mounting options allows you to further tailor the X-Series to meet your needs. Choose from IntelliTouch® surface acoustic wave (SAW), AccuTouch® five-wire resistive or TouchPro™ projected capacitive (PCAP) touch technologies to meet the demands of your environment. With processor options that scale from the value-based Intel Celeron J1900 to the high-performance Intel Core i5, the Elo X-Series is one of the most powerful systems in its class.

Versatility.
Every X-Series system is built with transactions in mind, and the wide assortment of peripheral options reflect just that. Whether for staff- or guest-facing applications, easily attach any combination of up to three peripherals, including an EMV reader, a near-field communication (NFC/RFID) reader, mag stripe reader (MSR), barcode reader or fingerprint scanner to the bezel of the X-Series via a universal snap-in connector. To enhance customer engagement at checkout, choose from a wide array of customer facing displays ranging from 2-line to 20-inch. For self-service applications, transform the Elo X-Series from counter-top terminal to kiosk with the optional wall-mount kit.

Reliability.
Rigorously tested and backed by a three-year warranty, the X-Series delivers superior quality and reliability. The splash-proof housing and rugged retail-hardened design easily withstand the adverse conditions associated with most commercial environments. The unique, modular chassis provides easy access to storage and memory for quick, tool-less service.

Display

Display diagonal

38.1 cm (15")

Display resolution

1024 x 768 pixels

Touchscreen

Y

Display brightness

212.2 cd/m²

Touchscreen technology

Projected capacitive system

Contrast ratio (typical)

700:1

Viewing angle, horizontal

165°

Viewing angle, vertical

150°

Response time

16 ms

Effective viewing area

304.12 x 228.1 mm

Aspect ratio

4:3

Display number of colours

16.2 million colours

Processor

Processor frequency

2.41 GHz

Processor family

Intel® Celeron®

Processor model

J1900

Processor cores

4

Processor cache

2 MB

Processor threads

4

Memory

Internal memory

4 GB

Internal memory type

DDR3L-SDRAM

Number of memory slots

2

Memory slots type

SO-DIMM

Memory clock speed

1600 MHz

Storage

Total storage capacity

128 GB

Storage media

SSD

SSD capacity

128 GB

SSD interface

Serial ATA

Graphics

Graphics card manufacturer

Intel

Graphics card

HD Graphics

Features

Certification

UL, cUL , FCC, IC, TUV, CE, CB, CoC, VCCI, CCC, RCM, SRRC

Multimedia

Built-in speaker(s)

Y

Number of speakers

2

Network

Ethernet LAN

Y

Wi-Fi

Y

Wi-Fi standards

802.11b,802.11g,Wi-Fi 4 (802.11n)

Ports & interfaces

Ethernet LAN (RJ-45) ports

1

USB 2.0 ports quantity

4

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

2

Powered USB

Y

VGA (D-Sub) ports quantity

2

Line-out

Y

Microphone in

Y

RS-232 ports

1

DC-in jack

Y

Design

Product colour

Black

Performance

Trusted Platform Module (TPM)

Y

Trusted Platform Module (TPM) version

1.2

Software

Operating system installed

Windows 7 Professional

Power

AC input voltage

100-240 V

AC input frequency

50 - 60 Hz

Power supply

100 W

Power consumption (typical)

33 W

Operational conditions

Operating relative humidity (H-H)

20 - 80%

Operating temperature (T-T)

0 - 35 °C

Storage temperature (T-T)

-20 - 60 °C

Storage relative humidity (H-H)

5 - 95%

Ergonomics

VESA mounting

Y

Panel mounting interface

100 x 100 mm

On Screen Display (OSD)

Y

Mean time between failures (MTBF)

50000 h

Weight & dimensions

Width

368.1 mm

Depth

62.2 mm

Height

312 mm

Width (with stand)

365.2 mm

Depth (with stand)

251.7 mm

Height (with stand)

348.8 mm

Weight

4.31 kg

Weight (with stand)

6.89 kg

Packaging data

Package width

482 mm

Package depth

352 mm

Package height

442 mm

Package weight

9.95 kg

Technical details

Sustainability certificates

ENERGY STAR
