Performance

Maximum video resolution

1920 x 1080 pixels

Video compression formats

H.264, H.265

Audio formats supported

G.711 A-law

Video capturing speed

30 fps

Video capturing speed (PAL)

25 fps

Video capturing speed (NTSC)

30 fps

Product colour

Black

Playback modes

Fast Backward, Fast forward, Slow backward, Slow forward

LED indicators

Yes

USB connectivity

Yes

Video streaming

Yes

Audio streaming

Yes

Dual stream support

Yes

Input bandwidth

8 Mbit/s

Ports & interfaces

Video input channels

8 channels

BNC input ports

8

HDMI ports quantity

1

USB 2.0 ports quantity

2

Network

Ethernet LAN

Yes

Ethernet interface type

Fast Ethernet

Ethernet LAN (RJ-45) ports

1

Ethernet LAN data rates

10,100 Mbit/s

Hard drive

Number of HDDs supported

1

HDD capacity

12 TB

Supported HDD interfaces

Serial ATA

Power

Power supply type

DC

DC voltage

12 V

Power consumption (max)

4 W

DC current (max)

2 A

Weight & dimensions

Width

215 mm

Depth

230 mm

Height

47 mm

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

0 - 90%
